Product Information

Overview:

These high-quality dBoots tires, mounted on ARRMA wheels, are direct replacements for your kit items.

Features:

Tires: Multi-surface all-road tires for awesome traction in all conditions - Molded-in belt to aid stability at high speeds - High-quality rubber for long-lasting durability - Pre-glued for trouble-free fit and servicing

Wheels: Multi-spoke design for stylish looks and increased strength - Tough nylon for durability on all surfaces - Black color for head-turning ARRMA styling - 17mm Hex for strength during extreme driving action and easy servicing

Inserts: High-quality inserts with excellent support for the tire tread - Specially designed to give the perfect balance of aggressive grip and easy handling characteristics

TECHNICAL INFORMATION:

Inner Wheel bead diameter: 3.27" (83mm)

Outer Wheel bead diameter: 2.95" (75mm)

Width: 2.09" (53mm)

Wheel hex size: 17mm

Overall diameter: 4.21" (107mm)

Includes:

2 x Black Five Spoke Wheels with pre-glued dBoots Hoons tires

Requires:

To use 107mm diameter tires on the rear axle of your vehicle and 100mm diameter tires on the front axle you must change the ratio of the gearboxes to account for the different rollout values. To do this use GP5 gears in the front gearbox and GP6 gears in the rear gearbox:

FRONT:

ARA311016 - MAIN INPUT GEAR 15T GP5

ARA311017 - MAIN DIFF GEAR 42T GP5

REAR:

ARA311018 - MAIN INPUT GEAR 14T GP6

ARA311019 - MAIN DIFF GEAR 45T GP6
